Nordic NRF51822 Bluetooth Ble 4.2 Module Small Wearable Cansec WB822D

Name: Nordic NRF51822 Bluetooth Ble 42 Module Small Wearable Cansec WB822D
Brand: Cansec Wireless
Price: 3.11 USD

Quality Nordic NRF51822 Bluetooth Ble 4.2 Module Small Wearable Cansec WB822D wholesale

Brand Name : Cansec Wireless

Model Number : WD822D

Place of Origin : Beijing

MOQ : 100

Price : USD 3.11$ per piece

Payment Terms : T/T

Supply Ability : 20000000 units per year

Delivery Time : 5-8 weeks

Packaging Details : Three layers of protection anti-static bag & moisture-proof & cardboard box ensure transportation safety

Chipset : nrf51822

Application : IoT

Size : 8*8*1.7mm

Operating Voltage : 2.1-3.6V

TX Power : 3dBm

RX Sensitivity : -93dBm

Sleep Current Consumption : 1μA

Contact Now

Small Size Wearable Cansec 2.4Ghz IoT Control Module WB822D Nordic NRF51822-CEAA 4.2 Ble Module

Nordic NRF51822 Bluetooth Ble 4.2 Module Small Wearable Cansec WB822D

Parameter		Min	Typ	Max	Unit
Operating Voltage		2.1	-	3.6	V
Operating Temperature		-20	-	+70	℃
Current Consumption	Sleep Mode	-	1	-	uA
	Receive mode	-	15	-	mA
	Transmit Mode @output power max	-	13	-	mA
TX Power (For Carrier)		-	-	3	dBm
RX Sensitivity (For Lora Modulation)		-	-	-93	dBm
Distance		30			m

Small Size Wearable Cansec 2.4Ghz IoT Control Module WB822D Nordic NRF51822-CEAA 4.2 Ble Module

1. WB822D Module is designed based on nRF51822 RF SoC chip of NORDIC company.

2. nRF51822 is an ultra-low-power 2.4GHz wireless System on Chip (SoC) integrating the nRF51 series 2.4GHz transceiver, a 32bit ARM Cortex-M0 CPU, flash memory, and analogue and digital peripherals.

3. nRF51822 can support Bluetooth low energy and a range of proprietary 2.4GHz protocols, such as Gazell from Nordic Semiconductor.

Nordic NRF51822 Bluetooth Ble 4.2 Module Small Wearable Cansec WB822D

FAQ
 Q1: Are you a factory or trade company?
 A1: We are a professional factory with 25 years experience.
 Q2: Can you accept OEM/ODM?
 A2: Sure, we have rich OEM&ODM experience.
 Q3: Do you have quality assurance?
 A3; Each of our products has undergone quality testing and has two years of free after-sales service.
